V-Ref Precision 4.096V 7mA 8-Pin SOIC N

The ISL21009 FGA voltage references are extremely lowpower, high precision, and low noise voltage referencesfabricated on Intersil’s proprietary Floating Gate Analogtechnology. The ISL21009 features very low noise (4.5µVP-Pfor 0.1Hz to 10Hz), low operating current (180µA, Max), and3ppm/°C of temperature drift. In addition, the ISL21009family features guaranteed initial accuracy as low as±0.5mV. This combination of high initial accuracy, low power and lowoutput noise performance of the ISL21009 enables versatilehigh performance control and data acquisition applicationswith low power consumption.

• Output Voltages is 1.250V, 2.500V, 4.096V, 5.000V
• Initial Accuracy is ±0.5mV, ±1.0mV, ±2.0mV
• Input Voltage Range is 3.5V to 16.5V
• Output Voltage Noise is 4.5µVP-P (0.1Hz to 10Hz)
• Supply Current is 180µA (Max)
• Temperature Coefficient is 3ppm/°C, 5ppm/°C, 10ppm/°C
• Output Current Capability is Up to ±7.0mA
• Operating Temperature Range is -40°C to +125°C
• Package is 8 Ld SOIC
• Pb-Free (RoHS Compliant)
