V-Ref Precision 3V 7mA 8-Pin SOIC N

The ISL21007 FGA voltage references are extremely low power, high precision, and low noise voltage references fabricated on Intersil’s proprietary Floating Gate Analog technology. The ISL21007 features very low noise (4.5µVP-P for 0.1Hz to 10Hz) and very low operating current (150µA, Max). In addition, the ISL21007 family features guaranteed initial accuracy as low as ±0.5mV

• Reference Output Voltage : 1.250V, 2.048V, 2.500V, 3.000V
• Low Output Voltage Noise : 4.5µVP-P (0.1Hz to 10Hz)
• Supply Current : 150µA (Max)
• Temperature Coefficient : 3ppm/°C (B grade)
• Operating Temperature Range -40°C to +125°C
• Package 8 Ld SOIC
• Pb-Free (RoHS Compliant)
