Telecom Transformer 1:1 1500Vrms -3dB/-1dB Surface Mount
Telecom Transformer 1:1 1500Vrms -3dB/-1dB Surface Mount
- ROHS COMPLAINT
- HEADER: DAP (DIALLYL PHTHALATE) WITH FLAMMABILITY RATING IL 94V-0 OR BETTER.
- STORAGE TEMPERATURE: 20°C TO +125°C
Характеристики
| Бренд | Pulse Electronics |
|---|---|
| Описание продукта | 17.73 x 14.86 x 6.86 |
| Lead Style | Gull wing |
| Длина | 17.73 mm |
| Turns Ratio | 1:1 |
| Schedule B | 8504312000 |
| HTSN | 8504312000 |
| Рабочая температура | 0 to 70 °C |
| Страна происхождения | Китай |
| Transform | 10GBase-T Magnetics Module Transformer |
| Maximum O | 0.18(Min) mH |
| Supplier | DIP SMD |
| Package Type | 30DIP SMD |
| Minimum C | -40@1MHz to 100MHz/-30@100MHz to 500MHz dB |
| Minimum Cmrr | -37@1MHz to 100MHz/-30@100MHz to 300MHz/-25@300MHz to 500MHz dB |
| Minimum R | -23@1MHz|-25@2MHz to 100MHz dB |
| Maximum I | -3@100KHz/-1@1MHz to 400MHZ dB |
SKU: H7137FNL
