QorIQ LS1024A 32-bit Communications Processor Reference Design Board

The QorIQ LS1024A communications processor addresses a wide variety of applications ranging from high-end VoIP and video-enabled home gateways, small-to-mid-sized business (SMB) and high performance security appliances to Ethernet powered 802.11n enterprise access points and consumer networked attached storage products. The QorIQ LS1024A reference design board (LS1024ARDB) is a compact form-factor tool that enables evaluation of the LS1024A solution for these and other low-end networking applications. The LS1024ARDB also features an expansion connector suitable for adding additional components such as an LCD panel.

Processor

• Single or dual ARM Cortex-A9 SMP/AMP 32-bit cores, with NEON DSP & FPU, up to 1.2 GHz
• 32 KB instruction and data caches
• 256 KB shared L2 cache

Memory

• Default 256MB DDR3 (Support for 512MB DDR3)
• 64MB NOR FLASH
• 2GB NAND Flash
• 64MB SPI Nor FLASH
• 64KB I2C EEPROM

Ethernet

• 4x GbE LAN connectors
• 2x GbE WAN connector
• 1x SFP+ connector

Basic Peripherals and Interconnect

• 4 PORT SMSC USB3.0 HUB
  • 2x USB TYPE 3.0A Connectors
• 2 Mini PCI EXPRESS Connectors
• 1 PORT USB2.0 Controller
• 1 UAB TYPE 2.0A Connector
• SERDES
  • 1x PCI EXPRESS
  • 2x Mini PCI Express Connectors
  • 2x SATA Connectors
• DECT
  • One Adaptor Socket on board
• Voice
  • 2 FXS Ports (ZL88601 Dual Wide Band SLIC)
• UART
  • UART0 is connected to on board DB9 connector
  • UART1 is brought to 5 pin connector
• EXPANSION 128 Pin High Density Connector
  • Expansion Bus
  • SPI Bus
  • TDM Bus
  • I2C Bus
  • UART Busses
  • GPIO
  • System and External Reset
  • Power
• LCD Connector
  • Expansion Bus
  • SPI Bus

Additional Features

• PMIC for voltage control
