Processor Supervisor 2.19V 2.5V/3V/3.3V/5V 5-Pin SOT-23 T/R

The ISL88013IH529Z-TK is family of device which offer both fixed and/or adjustable voltage-monitoring that combine popular functions such as Power-On reset control, watchdog timer, supply voltage supervision, and manual reset assertion in a small 5 Ld SOT-23 package. Unique features on the ISL88013IH529Z-TK include a watchdog timer with a 51s start-up timeout and a 1.6s normal timeout duration.

• Single/dual voltage monitoring supervisors
• Dual supervisor has one fixed voltage input and another that is user-adjustable down to 0.6V
• Adjustable POR timeout delay options
• Watchdog timer with 1.6s normal and 51s start-up timeout durations
• Manual reset input on all devices
• Reset signal valid down to VDD = 1V
• Accurate ±1.5% voltage threshold
• Immune to power-supply transients
• Ultra low 5.5µA supply current
• Small 5 Ld SOT-23 Pb-Free package
• Pb-Free (RoHS Compliant)
