OP Amp Single GP ±5.5V 8-Pin SOIC N

The HFA1110 is a unity gain closed loop buffer that achieves -3dB bandwidth of 750MHz, while offering excellent video performance and low distortion. • Wide -3dB Bandwidth. . . . . . . . . . . . . . . . . . . . . . 750MHz
• Very Fast Slew Rate. . . . . . . . . . . . . . . . . . . . . . 1300V/?s
• Fast Settling Time (0.2%). . . . . . . . . . . . . . . . . . . . . . 7ns
• High Output Current . . . . . . . . . . . . . . . . . . . . . . . . . 60mA
• Fixed Gain of +1
• Gain Flatness (100MHz) . . . . . . . . . . . . . . . . . . . . 0.03dB
• Differential Phase. . . . . . . . . . . . . . . . . . . . . . . . . . 0.025°
• Differential Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.04%
• 3rd Harmonic Distortion (50MHz). . . . . . . . . . . . . . -80dBc
• 3rd Order Intercept (100MHz) . . . . . . . . . . . . . . . . 30dBm
• Pb-Free Plus Anneal Available (RoHS Compliant)
