Module DC-DC 1-OUT 5V 2A 10W 6-Pin

The BXA10 series of dc-dc converters, comprising 7 different models, is designed for a wide range of applications including communications, industrial systems and mobile battery powered systems Packing up to 10 Watts of power into a 2 x 1 x 0.395 inch package, with efficiencies as high as 85%, the BXA10 has wide input ranges of 9 Vdc to 18 Vdc and 18 Vdc to 75 Vdc, and is available in single and dual output versions.

• 5V Output Voltage
• 1 x 2 x 0.395 inch package with stand-offs
• 13.3 Watts/in3 power density
• CISPR22 and EN55022 conducted emission level A
• UL, CSA and VDE approvals (48V input only)
• Continuous short circuit protection
• Optional remote ON/OFF
• Available RoHS compliant
• 2 year warranty
• Input current is 0.26A
