MAX17502 Ultra-Small High-Efficiency Synchronous Step-Down DC-DC Converter Evaluation Kit

The MAX17502F evaluation kit (EV kit) provides a proven design to evaluate the MAX17502F high-efficiency, high-voltage, synchronous step-down DC-DC converter. The EV kit uses the device to generate a fixed 5V at load currents up to 1A from a 7V to 60V input supply. The device features a forced-PWM control scheme that provides constant switching-frequency operation at all load and line conditions.

• Operates from a 7V to 60V Input Supply
• 5V Fixed Output Voltage
• 1A Output Current
• 600kHz Switching Frequency
• Enable/UVLO Input
• Resistor-Programmable UVLO Threshold
• Open-Drain Active-Low RESET Output
• Overcurrent and Overtemperature Protection
• Proven PCB Layout
• Fully Assembled and Tested
