Low Drop Linear Voltage Regulator

This device is a 5-V low drop fixed-voltage regulator. The maximum input voltage is 42 V (65 V, = 400 ms). Up to an input voltage of 26 V and for an output current up to 650 mA it regulates the output voltage within a 2% accuracy. The short circuit protection limits the output current of more than 650 mA. The device incorporates overvoltage protection and a temperature protection which turns off the device at high temperatures.

Output voltage tolerance  =   ± 2%

650 mA output current capability

Low-drop voltage

Reset functionality

Adjustable reset time

Suitable for use in automotive electronics

Integrated overtemperature protection

Reverse polarity protection

Input voltage up to 42 V

Overvoltage protection up to 65 V ( =  400 ms)

Short-circuit proof

Wide temperature range

ESD protection:  ± 2kV HBM ¹⁾

Green Product (RoHS compliant)

AEC Qualified
