LAN9303 PHY Switch Daughter Board

Microchips LAN9303 Switch PHY Daughter Board is populated with a high-performance, small-footprint, full-featured 3-port managed LAN9303 Ethernet switch and a 2 port Base-TX MAGJACK connector. It is designed for easy development of RMII Ethernet control applications when plugged into the PIC32 compatible Starter Kits. The LAN9303 Switch PHY Daughter Board (AC320004-4) enables Ethernet communication with the starter kits listed below. PIC32MZ EC Starter Kit PIC32MZ EC Starter Kit with Crypto Engine PIC32 Ethernet Starter Kit II

• High-performance, full-featured 3-port switches with per-port IEEE 802.1Q VLAN support (up to 16 VLAN groups)
• Industry"s highest (±8kV/15kV) per-port ESD protection
• IGMP v1/v2 monitoring for multicast packet filtering
• Up to 200 Mbps network speed via a Turbo MII interface
• Optional EEPROM or external CPU serial management support via an I2C™ interface
• Virtual PHY feature simplifies software development by mimicking multiple switch ports as a single-port PHY
• Integrated regulators require a single 3.3V supply
