ISL12057 I2C Real Time Clock/Calendar Evaluation Board

The ISL12057 device is a low-power, real-time clock that is pin compatible and functionally equivalent to Maxim DS1337 with clock/calendar and alarm function. The oscillator uses an external, low-cost 32.768kHz crystal with 6pF load capacitance. The real-time clock tracks time with separate registers for hours, minutes, and seconds. The device has calendar registers for date, month, year, and day of the week. The calendar is accurate through 2099, with automatic leap year correction.

• Real-Time Clock/Calendar
• Dual Interrupts for Frequency Output and Alarm interrupts
• Four Selectable Frequency Outputs
• Two Alarms
• Small Package Options
  • 8 Ld 2mmx2mm UTDFN
  • 8 Ld MSOP
  • 8 Ld SOIC
  • Pb-Free (RoHS Compliant)
