I2C Touch Screen Controller 16-Pin TSSOP T/R

The TSC2003 is a 4-wire resistive touch screen controller. It also features direct measurement of two batteries, two auxiliary analog inputs, temperature measurement, and touchpressure measurement. The TSC2003 has an on-chip 2.5V reference that can be utilized for the auxiliary inputs, battery monitors, and temperature- measurement modes. The reference can also be powered down when not used to conserve power. The internal reference will operate down to 2.7V supply voltage while monitoring the battery voltage from 0.5V to 6V. The TSC2003 is available in the small TSSOP-16 and VFBGA-48 packages and is specified over the –40°C to +85°C temperature range.

2.5V TO 5.25V OPERATION

INTERNAL 2.5V REFERENCE

DIRECT BATTERY MEASUREMENT (0.5V TO 6V)

ON-CHIP TEMPERATURE MEASUREMENT

TOUCH-PRESSURE MEASUREMENT

I²C INTERFACE SUPPORTS:
Standard, Fast, and High-Speed Modes

AUTO POWER DOWN

TSSOP-16 AND VFBGA-48 PACKAGES

APPLICATIONS

• PERSONAL DIGITAL ASSISTANTS
• PORTABLE INSTRUMENTS
• POINT-OF-SALES TERMINALS
• PAGERS
• TOUCH SCREEN MONITORS
• CELLULAR PHONES
