High Side Driver 24-Pin PowerSSO EP T/R

The VNQ5027AK-E is a monolithic device made using STMicroelectronics VIPower technology. It is intended for driving resistive or inductive loads with one side connected to ground. Active VCC pin voltage clamp protects the device against low energy spikes (see ISO7637 transient compatibility table).This device integrates an analog current sense which delivers a current proportional to the load current (according to a known ratio) when CS_DIS is driven low or left open. When CS_DIS is driven high, the CURRENT SENSE pin is in a high impedance condition. Output current limitation protects the device in overload condition. In case of long overload duration, the device limits the dissipated power to safe level up to thermal shut-down intervention. Thermal shut-down with automatic restart allows the device to recover normal operation as soon as fault condition disappears.

Output current: 42A

3.0V CMOS compatible input

Current sense disable

Proportional load current sense

Undervoltage shut-down

Overvoltage clamp

Thermal shut down

Current and power limitation

Very low stand-by current

Protection against loss of ground and loss of V_CC

Very low electromagnetic susceptibility

Optimized electromagnetic emission

Reverse battery protection (see Application schematic)

In compliance with the 2002/95/EC European directive

Package: ECOPACK®
