FUSB302T Programmable USB Type-C Controller Evaluation Board

The FUSB302TGEVB evaluation board targets system designers looking to implement a DRP/SRC/SNK USB Type-C connector with low amount of programmability.The FUSB302TGEVB enables the USB Type-C detection including attach, and orientation. The FUSB302 integrates the physical layer of the USB BMC power delivery protocol to allow up to 100 W of power and role swap. The BMC PD block enables full support for alternative interfaces of the Type-C specification.Reference code is available for the FUSB302 for easy implementation of Type-C and USB BMC power delivery protocol across several embedded controller platforms. Click on the Reference Code request link to the right.

• Full Type-C 1.1 Support. Integrates the following functionality of the CC pin
• Dedicated devices can operate both on a Type-C receptacle or a Type-C plug with a fixed CC and VCONN channel
• Software configurable either as a dedicated host, dedicated device, or dual role
• Dual-Role Functionality with Autonomous DRP Toggle
• Ability to connect as either a host or a device based on what has been attached
• Attach/Detach Detection as Host
