Full Bridge Motor Driver 20-Pin SOIC W
Full Bridge Motor Driver 20-Pin SOIC W
- Two Independent Controlled Complementary MOS Power Output Half H-Drivers (Full-Bridge) for Nominal 3V to 12V Power Supply Operation
- Split ±Voltage Power Supply Option for Output Drivers
- Load Switching Capabilities to 0.5A
- Single Supply Range +2.5V to +15V
- Low Standby Current
- CMOS/TTL Compatible Input Logic
- Over-Temperature Shutdown Protection
- Overcurrent Limit Protection
- Overcurrent Fault Flag Output
- Direction, Braking and PWM Control
- Pb-Free Plus Anneal Available (RoHS Compliant)
Характеристики
| Бренд | Renesas Electronics |
|---|---|
| Type Prod | Full Bridge Motor Driver |
| Schedule B | 8542390000 |
| Страна происхождения | United States |
| Рабочая температура | -40 to 85 °C |
| Описание продукта | 13 x 7.6 x 2.35 mm |
| Msl Level | 1 |
| Lead Finish | Tin/Lead |
| Maximum O | 1.5 mA |
| Supplier | SOIC W |
| Max Proce | 240|300 |
| HTSN | 8542390001 |
SKU: HIP4020IB
