Evaluation Board For ISL8502

The ISL8502 is a synchronous buck controller with internal MOSFETs packaged in a small 4mm x 4mm QFN package. The ISL8502 can support a continuous load of 2A and has a very wide input voltage range. With the switching MOSFETs integrated into the IC, the complete regulator footprint can be very small and provide a much more efficient solution than a linear regulator. The switching PWM controller drives two internal N-Channel MOSFETs in a synchronous-rectified buck converter topology. The synchronous buck converter uses voltage-mode control with fast transient response. The switching regulator provides a maximum static regulation tolerance of ±1% over line, load, and temperature ranges. The output is user-adjustable by means of external resistors down to 0.6V.

• Up to 2A Continuous Output Current
• Integrated MOSFETs for Small Regulator Footprint
• Adjustable Switching Frequency, 500kHz to 1.2MHz
• Tight Output Voltage Regulation, ±1% Over-Temperature
• Wide Input Voltage Range, 5V ±10% or 5.5V to 14V
• Wide Output Voltage Range, from 0.6V
• Simple Single-Loop Voltage-Mode PWM Control Design
• Input Voltage Feed-Forward for Constant Modulator Gain
• Fast PWM Converter Transient Response
• Lossless rDS(ON) High Side and Low Side Overcurrent Protection
• Undervoltage Detection
• Integrated Thermal Shutdown Protection
• Power-Good Indication
• Adjustable Soft-Start
• Start-Up with Pre-Bias Output
• Pb-free (RoHS Compliant)
