Evaluation Board For ISL28634 Programmable Gain Instrumentation Amplifier

The ISL28634 is 5V zero-drift rail-to-rail input/output Programmable Gain Instrumentation Amplifiers (PGIA). These instrumentation amplifiers feature low offset, low noise, low gain error and high CMRR. They are ideal for high precision applications over the wide industrial temperature range. These instrumentation amplifiers are designed with a unique 2-bit, 3-state logic interface that allows up to 9 selectable gain settings. The ISL28634 single-ended output includes an additional uncommitted zero-drift amplifier, useful to buffer the REF input or used as a precision amplifier. The ISL28634 differential output amplifier includes a reference pin to set the common-mode output voltage to interface with differential input ADCs.

• Ultra high precision front-end amplifier
• Zero-drift instrumentation amplifier
• Pin selectable 9 gain settings: G = 1 to 1,000
• Rail-to-rail input/output
• Single-ended output
• Differential output
• RFI filtered inputs improve EMI rejection
• Single supply 2.5V to 5.5V
• Dual supply ±1.25V to ±2.75V
• Low input offse t5µV, Maximum
