Evaluation Board For ISL28194

The ISL28194 is micropower op amps optimized for low-power applications. The part is designed for single-supply operation from 1.8V to 5.5V, making it suitable for applications with two 1.5V alkaline batteries. The ISL28194 consumes typically 330nA of supply current . The part feature rail-to-rail input and output swing (RRIO), allowing for maximum battery usage. Equipped with a shutdown pin, the part draw typically 2nA when off. The combination of small footprint, low power, single supply, and rail-to-rail operation makes it ideally suited for all battery operated device.

• Typical Supply Current 330nA
• Ultra-Low Single-Supply Operation Down to +1.8V
• Rail-to-Rail Input/Output Voltage Range (RRIO)
• Maximum 2mV Offset Voltage
• Maximum 60pA Input Bias Current
• 3.5kHz Gain Bandwidth Product
• ENABLE Pin Feature
• -40°C to +125°C Operation
• Pb-Free (RoHS Compliant)
