Diode TVS Single Uni-Dir 15.3V 1.5KW 2-Pin Case 1.5KE Bulk
Diode TVS Single Uni-Dir 15.3V 1.5KW 2-Pin Case 1.5KE Bulk
- Glass passivated chip junction
- Available in uni-directional
- 1500 W peak pulse power capability with a 10/1000 µs waveform, repetitive rate (duty cycle): 0.01 %
- Excellent clamping capability
- Very fast response time
- Low incremental surge resistance
- AEC-Q101 qualified
- Solder dip 275 °C max. 10 s, per JESD 22-B106
- Stand-Off Voltage : 15.3V
Характеристики
| Бренд | Vishay |
|---|---|
| Max Proce | 260 |
| Configuration | Single |
| Supplier | Case 1.5KE |
| Esd Protection | Нет |
| Рабочая температура | -55 to 175 °C |
| Maximum C | 25.2 V |
| Maximum P | 59.5 A |
| Описание продукта | 9.5 x 5.3 x 5.3 mm |
| Maximum R | 1 uA |
| Lead Finish | Matte Tin |
| Direction Type | Uni-Directional |
| Test Current | 1 mA |
| Minimum B | 17.1 V |
| Maximum R | 15.3 V |
| Schedule B | 8541100050 |
| HTSN | 8541100050 |
| Страна происхождения | Китай |
SKU: 1N6277A-E3/51
