DAC 1-CH Segment 12-bit 28-Pin TSSOP EP T/R
The ISL76161 is a 12-bit, 130MSPS (Mega-Samples Per Second), CMOS, high speed, low power, D/A (digital to analog) converter, designed specifically for use in radar systems or high performance communication systems, such as base transceiver stations utilizing 2.5G or 3G cellular protocols.
- High Speed 130MSPS
- Low Power 103mW with 20mA Output at 130MSPS
- Adjustable Full Scale Output Current 2mA to 20mA
- Excellent Spurious Free Dynamic Range (73dBc to Nyquist, fS = 130MSPS, fOUT = 10MHz)
- Automotive Qualified Component
- Extended Temperature Operation: -40°C to +105°C
- +3.3V Power Supply
- 3V LVCMOS Compatible Inputs
- UMTS Adjacent Channel Power = 70dB at 19.2MHz
- EDGE/GSM SFDR = 90dBc at 11MHz in 20MHz Window
- Pb-Free (RoHS Compliant)
Характеристики
| Бренд | Renesas Electronics |
|---|---|
| Schedule B | 8542390000 |
| Number Of | 1 |
| Digital S | Да |
| Number Of | 1 |
| Operating | 3.6|2.7|3.3 V |
| Voltage R | Internal|External |
| Output Polarity | Unipolar |
| Output Type | Current |
| Screening Level | Automotive |
| Рабочая температура | -40 to 105 °C |
| Resolution | 12 Bit |
| Digital I | Parallel |
| Architecture | Segment |
| Power Sup | Analog|Digital |
| HTSN | 8542390001 |
| Страна происхождения | United States |
| Max Proce | 260 |
| Supplier | TSSOP EP |
| Conversion Rate | 130 Msps |
| Описание продукта | 9.8 x 4.5 x 1.05 mm |
| Lead Finish | Matte Tin |
| Full Scal | 3 % of FSR |
| Msl Level | 3 |
| Integral | 1.25 LSB |
SKU: ISL76161AVZ-TK
