DAC 1-CH Segment 10-bit 28-Pin TSSOP
The ISL5757 is a 10-bit, 260+MSPS (Mega Samples Per Second), CMOS, high speed, low power, D/A (digital to analog) converter, designed specifically for use in high performance communication systems such as base transceiver stations utilizing 2.5G or 3G cellular protocols. This device complements the ISL5x57 family of high speed converters, which include 10, 12, and 14-bit devices.
- Low Power 103mW with 20mA Output at 130MSPS
- Adjustable Full Scale Output Current 2mA to 20mA
- +3.3V Power Supply
- 3V LVCMOS Compatible Inputs
- Excellent Spurious Free Dynamic Range (71dBc to Nyquist, fS = 130MSPS, fOUT = 10MHz)
- UMTS Adjacent Channel Power = 65dB at 19.2MHz
- EDGE/GSM SFDR = 83dBc at 11MHz in 20MHz Window
- Pin compatible, 3.3V, Lower Power Replacement For The AD9750 and HI5760
- Pb-Free Available (RoHS Compliant)
Характеристики
| Бренд | Renesas Electronics |
|---|---|
| Schedule B | 8542390000 |
| Number Of | 1 |
| Digital S | Да |
| Number Of | 1 |
| Operating | 3.6|2.7|3.3 V |
| Voltage R | Internal|External |
| Output Polarity | Unipolar |
| Output Type | Current |
| Screening Level | Industrial |
| Рабочая температура | -40 to 85 °C |
| Resolution | 10 Bit |
| Digital I | Parallel |
| Architecture | Segment |
| Power Sup | Analog|Digital |
| HTSN | 8542390001 |
| Страна происхождения | United States |
| Max Proce | 260|300 |
| Supplier | TSSOP |
| Conversion Rate | 260 Msps |
| Описание продукта | 9.7 x 4.4 x 0.9 mm |
| Lead Finish | Matte Tin |
| Full Scal | 3 % of FSR |
| Msl Level | 3 |
| Integral | 0.5 LSB |
SKU: ISL5757IAZ
