Controller 36-Pin QFN EP T/R

The ZL2005P is an innovative mixed-signal power conversion and management IC that combines a compact, efficient, synchronous DC-DC buck controller, adaptive drivers and key power and thermal management functions in one IC, providing flexibility and scalability while decreasing board space requirements and design complexity. Zilker Labs Digital-DC technology enables a unique blend of performance and features not available in either traditional analog or newer digital approaches, resolving the issues associated with providing multiple low-voltage power domains on a single PCB. The ZL2005P is designed to be configured either as a standard ZL2005 or as POLA/DOSA compatible device. All operating features can be configured by simple pin-strap selection, resistor selection or through the on-board serial port. The PMBus-compliant ZL2005P uses the SMBus serial interface for communication with other Digital-DC products or a host controller.

• Efficient synchronous buck controller
• 3 V to 14 V input range
• 0.54 V to 5.5 V output range (with margin)
• Optional output voltage setting with VADJ pin
• ± 1% output accuracy
• Internal 3 A drivers support >40 A power stage
• Fast load transient response
• Phase interleaving
• RoHS compliant (6 x 6 mm) QFN package
• Digital soft start/stop
• Precision delay and ramp-up
• Voltage tracking, sequencing and margining
• Voltage/current/temperature monitoring
• I2 C/SMBus communication
• Output overvoltage and over current protection
• Internal non-voltatile memory (NVM)
• PMBus compliant
