Connector Accessories Right Button Ejector Card Header
Connector Accessories Right Button Ejector Card Header
- Mounts to 3M’s CompactFlash™ Type II, Long Guide, Surface Mount Headers
- Modular "snap on" design and multiple button types for design flexibility
- Can be used with either top or bottom mount (normal or inverse polarization) headers
- Latching retainer is used with normal polarization 3M"s Compact Flash™ Type II headers
- Latching Retainer can be also use with 3M™ Connector for CFast™ Card
- Latching Retainer provides enhanced retaining strength to the card and keeps it in place under high vibration environment
- Can be preassembled to connector to reduce handling and assembly time
- Meets CFA standards for known compatibility and reliability
- RoHS Compliant.
Характеристики
| Бренд | 3M |
|---|---|
| Schedule B | 8538907080 |
| HTSN | 8538908180 |
| Type Prod | Ejector |
| Описание продукта | 51.4 x 43.9 x 5.4 mm |
| Страна происхождения | Japan |
| Рабочая температура | -55 to 85 °C |
| Длина | 51.4 mm |
SKU: D7E50-8316-03
