Analog Switch Quad SPST 16-Pin TSSOP

The Intersil ISL43143IVZ device are CMOS, precision, quad SPST analog switches designed to operate from a single +2V to +12V supply or from a ±2V to ±6V supply. Targeted applications include battery powered equipment that benefit from the devices’ low power consumption low leakage currents (5nA max), and fast switching speeds (tON = 52ns, tOFF = 40ns). A 5? maximum RON flatness ensures signal fidelity, while channel-to-channel mismatch is guaranteed to be less than 2?.

• Fully Specified for 10% Tolerances at VS = ±5V and V+ = 12V, 5V and 3.3V
• Four Separately Controlled SPST Switches
• Pin Compatible with DG411/DG412/DG413
• ON Resistance (RON Max.) : 25?
• RON Matching Between Channels : <1µW
• Low Off Leakage Current (Max at 85°C) : 2.5nA
• TTL, CMOS Compatible
• Pb-Free Plus Anneal Available (RoHS Compliant)
