Analog Switch Quad SPST 16-Pin SOIC N

The ISL43142 is CMOS, precision, quad analog switches designed to operate from a single +2V to +12V supply or from a ±2V to ±6V supply. Targeted applications include battery powered equipment that benefit from the devices’ low power consumption (1uW), low leakage currents (1nA max), and fast switching speeds (tON = 30ns, tOFF = 18ns). A 12? maximum RON flatness ensures signal fidelity, while channel-to-channel mismatch is guaranteed to be less than 2.5?. The 3mm x 3mm Quad NoLead Flatpack (QFN) package alleviates board space limitations, making this newest line of low-voltage switches an ideal solution. The ISL43142 are quad single-pole/single-throw (SPST) devices.The ISL43142 has two NO and two NC switches and can be used as a dual SPDT, or a dual 2:1 multiplexer

• Fully Specified at ±5V, 12V, 5V, and 3V Supplies for 10% Tolerances
• Four Separately Controlled SPST Switches
• Pin Compatible with DG411/DG412/DG413
• ON Resistance (RON) 50?
• RON Matching Between Channels. 2?
• Low Charge Injection 5pC (Max)
• Low Power Consumption (PD) <1uW
• Low Leakage Current (Max at 85°C) 5nA
• Fast Switching Action
  • tON 30ns
  • tOFF 18ns
