Analog Switch Quad SPST 16-Pin SBCDIP

The HS-201HSRH-8 is monolithic CMOS analog switch featuring power-off high input impedance, very fast switching speeds and low ON-resistance. Fabrication on our DI RSG process assures SEL immunity and only very slight sensitivity to low dose rate (ELDRS). These Class V/Q devices are tested and guaranteed for 300krad (Si) total dose performance. Power-off high input impedance enables the use of this device in redundant circuits without causing data bus signal degradation. ESD protection, overvoltage protection, fast switching times, low ON-resistance, and guaranteed radiation hardness, make the HS-201HSRH ideal for any space application where improved switching performance is required.

• Electrically screened to DLA SMD# 5962-99618
• QML qualified per MIL-PRF-38535
• Radiation performance
  • High dose rate (50-300rad(Si)/s) 300krad(Si)
  • Low dose rate (0.01rad(SI)/s) 50krad(Si)
  • SEL immune DI RSG process
• Overvoltage protection (power on, switch off) ±30V
• Power off high impedance ±17V
• Fast switching times
  • tON 110ns (max)
  • tOFF 80ns (max)
• Low “ON” resistance ±10V to ±15V
• Wide analog voltage range (±15V supplies) ±15V
• TTL compatible
