ADC Single 2-Step Folding 40Msps 8-bit Parallel 24-Pin SOIC W
The HI5714 is a high precision, monolithic, 8-bit, Analog-to-Digital Converter fabricated in Intersil’ advanced HBC10 BiCMOS process.
•Sampling Rate . . . . . . . . . . . . . . . . . . .40/60/75/80 MSPS
•Low Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .325mW
•7.65 ENOB at 4.43MHz
•Overflow/Underflow Three-State TTL Output
•Operates with Low Level AC Clock
•Very Low Analog Input Capacitance
•No Buffer Amplifier Required
•No Sample and Hold Required
•TTL Compatible I/O
•Pin-Compatible to Philips TDA8714
•Pb-free Available
•Low Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .325mW
•7.65 ENOB at 4.43MHz
•Overflow/Underflow Three-State TTL Output
•Operates with Low Level AC Clock
•Very Low Analog Input Capacitance
•No Buffer Amplifier Required
•No Sample and Hold Required
•TTL Compatible I/O
•Pin-Compatible to Philips TDA8714
•Pb-free Available
Характеристики
| Бренд | Renesas Electronics |
|---|---|
| Screening Level | Commercial |
| Number Of | 1 |
| Polarity | Unipolar |
| Operating | 5.25|4.75|5 V |
| Number Of Adcs | 1 |
| Supplier | SOIC W |
| Digital I | Parallel |
| Рабочая температура | 0 to 70 °C |
| Input Voltage | 2.7 V |
| Input Type | Voltage |
| Lead Finish | Matte Tin |
| Input Sig | Single-Ended |
| Voltage S | Analog and Digital |
| Number Of | 1 |
| Sampling Rate | 40 Msps |
| Описание продукта | 15.6 x 7.6 x 2.35 mm |
| Voltage R | External |
| Max Proce | 260|300 |
| Schedule B | 8542390000 |
| HTSN | 8542390001 |
| Страна происхождения | Philippines |
| Integral | 0.75 LSB |
| Signal To | 48 dBFS |
| Msl Level | 3 |
| Maximum P | 375 mW |
| Typical P | 325 mW |
| Different | 0.4 LSB |
SKU: HI5714/4CBZ
