AC/DC Power Supply Single-OUT 5V 8A 40W 7-Pin

The AB40S series is a range of fully encapsulated AC/DC power modules. These high performance products feature an extended operating temperature range of -40°C to +80°C. Universal input voltage 85-264VAC and UL/IEC/EN safety approvals including medical safety and UL508 listing qualify these power supplies modules for applications in products with worldwide markets. EMI-filter meets EN55022, class B and FCC,part15, class B. The AB40S/D series power modules provide an economical solution for many space critical applications in commercial, medical and industrial electronic equipment.

• Fully encapsulated Plastic Case
• 3 Mounting Versions:
• PCB Mounting with Solder Pins
• Chassis Mounting with Screw Terminals
• DIN-Rail Mounting
• Package Dimension 88.9x63.5x30.0 mm (PCB Mounting Version)
• Universal Input 85-264VAC, 47-440 Hz
• Protection Class ll
• Extended Operating Temp.Range -40°C to +60°C at full Load
• LED Output Indicator (Chassis Version Models)
• Industrial Safety to UL/cUL/IEC/EN 60950-1 and UL508
• Medical Safety Approval to UL/cUL/IEC/EN 60601-1 3rd Edition
• Over Load and Over Temperature Protection
• 3 Year Product Warranty
