Accelerometer Single ±1.7g 5V 0.0012mV/g 8-Pin SMD T/R

The SCA610 accelerometer consists of a silicon bulk micro machined sensing element chip and a signal conditioning ASIC. The chips are mounted on a pre-molded package and wire bonded to appropriate contacts. The sensing element and ASIC are protected with silicone gel and lid. The sensor has 8 SMD legs (Gull-wing type).

• Single +5 V supply
• Current consumption 2.5 mA typical
• Ratiometric output in relation to supply voltage (Vdd = 4.75 V...5.25 V)
• Enhanced failure detection features o Digitally activated, true self-test by proof mass deflection using electrostatic force o Memory parity check during power up, and self-test cycle. o Built in connection failure detection
• Digitally activated, true self-test by proof mass deflection using electrostatic force
• Wide load drive capability (max. 20 nF)
• True DC response?
• Qualified according to AEC-Q100 standard
