3-Phase Bridge Driver 36-Pin DSO T/R

The TLE6280GP 3-phase bridge driver IC for MOSFET power stages with multiple protection functions.

• Compatible to very low ohmic normallevel input N-Channel Mosfets
• Separate input for each MOSFET
• PWM frequency up to 30kHz
• Fulfills specification down to 9V supply voltage
• Low EMC sensitivity and emission
• Separate Source connection for each MOSFET
• Adjustable dead time
• Adjustable dI/dt limitation
• Short circuit protection with adjustable current limitation
• Driver undervoltage warning
• Reverse polarity protection
• Disable function
• Input with TTL characteristics
• Error flag
• Thermal overload warning for driver IC
• Shoot through protection
• Shoot through option
• Integrated bootstrap diodes
• Green Product (RoHS compliant)
• AEC Qualified
